Welding equipment SET MIG MAG welding helmet, flux cored wire, accessories | MIG255A

SKU: M2255B1
GTIN: 4251210407196
Category: MIG MAG
Brands: VECTOR WELDING

Welding equipment SET MIG MAG welding helmet, flux cored wire, accessories | MIG255A

VECTOR WELDING MIG/MAG welding device MIG 255A

MIG/MAG 30-255A

2 cycle/ 4 cycle

MMA/electrode 30-170A

IGBT

suitable: wire coils 5kg (D200) & 15kg (D300)

COMPLETE SET: Welding device, welding helmet, 5kg flux-cored wire and accessories

410,92 €

excl. 19% VAT , plus (Standard)

Available immediately
Delivery time: 1 - 3 Workdays (DE - int. shipments may differ)

Article number: M2255B1

WELDING EQUIPMENT SET MIG 255A

The MIG 255A from Vector Welding is a MIG/MAG welding equipment with 30-255A in MIG/MAG mode, 30-170A in MMA mode, and 10-200A in TIG mode (optional).

The MIG/MAGWelding process with its automatic wire feed is suitable for many welding applications, even when working in hard-to-reach areas.

This set is a fully-equipped consisting of MIG MAG welding device MIG 255A, welding helmet, 5kg welding wire (wire roll), as well as an extensive accessory set (see scope of delivery)

MIG 255A PROPERTIES & ADVANTAGES:

MIG/MAG: Welding with automatic wire feed. In MIG welding argon (more rarely helium) is used as shielding gas, this process is preferably used for non-ferrous metals and stainless steel. The MAG process uses CO2 or a mixed gas of argon, CO2 and O2 as shielding gas and is mainly used for simple and low-alloy steel such as mild steel.
Settings according to wire thickness: If you set the wire thickness (0.6 | 0.8 | 1), an ampere (A) and wire feed speed adapted to the selected wire thickness appears. The amperage can be changed within the given range.
In SPL Mode, amps and volts can be set independently. A higher volt slows the wire speed down. A lower volt accelerates the wire feed. This is a great advantage when an individual setting is required. With the help of the job memory the settings can be saved and easily reused at a later date.
inductance: The device has a continuously adjustable choke. This smoothes the welding current and changes the rate of current rise so that the weld seam quality and / or precision is improved wi
2 cycles/4 cycles (MIG/MAG and TIG)
MMA/STICK/E-HAND: coated electrodes are used - in this process the electrodes are the arc carrier and filler metal in one.
hot start: every time the welding machine is restarted, overcurrent is provided and thus supports the ignition of the arc.
Arc Force: Melted material is transferred more easily to the workpieceover. Prevents the arc from being extinguished if contact between the electrode and the molten pool is caused by this material.
anti-stick automatically switches off the welding generator if the electrode sticks to the workpiece and has to be removed by hand without damaging the electrode clamp.
DC TIG welding ( optional: only possible with additional hose package and cables): Welding of almost all metals
Lift Arc: The ignition is triggered by contact with the welding cablethe workpiece, then the torch can be lifted and the welding process starts with the selected parameters.
modern IGBT (Insulated Gate Bipolar Transistor) enables fast and thus low-loss switching of electrical currents
overheating protection

MIG 255A FEATURES:

MIG 255A TECHNICAL DETAILS:

setting range welding current (MIG/MAG mode)	30 - 255 A
Adjustment range welding current (MMA/STICK mode)	30 - 170 A
Adjustment range welding current (TIG mode)	10 - 200 A
Duty cycle (ED) MIG/MAG 40°C	255 A at 25V 35%
Duty cycle (ED) MMA/STICK 40°C	170 A at 26.8V 35%
Duty cycle (ED) TIG 40°C	200 A at 18V 35%
Mains voltage	1 x 230 Volt
Mains frequency	50 - 60 Hz
Protection class	IP23
Dimensions in mm (L x W x H)	493 x 222 x 375
Weight in kg	11.5
Standards	EN60974-1 / IEC60974-1
wire diameter in mm	0.6/0.8/1

MIG 255A CONTROLLER:

1. On/Off	4. SWelding mode	7. 2 cycle/ 4 cycle
2. superheat display	5. display display display	8. selection of wire thickness
3. parameter setting	6. ampere/inductance/burn-back/volt

Shipping weight:	23,72 kg
Item weight:	17,67 kg

MIG 255TECHNICAL DETAILS:

Welding current setting range (MIG mode)	30 - 255 A
Welding current setting range (MMA/STICK mode)	30 - 170 A
Welding current setting range (TIG mode)	10 - 200 A
Duty cycle (ED) MIG40°C, 10 min	255 A at 26.7V 35%
Duty cycle (ED) MMA/STICK40°C, 10 min	170 A at 26.8V 35%
Duty cycle (ED) TIG40°C, 10 min	200 A at 18V 35%
Mains voltage	230V +/- 15%
Mains frequency	50 - 60 Hz
Effective input current	30A
Input current (max.)	50,7A
Required design of the single-phase generator	15 kVA
Protection class	IP23
Open circuit voltage (MIG/WIG/MMA)	60V DC
Wire guide roller	0,6/0,8/1
Gas sequence (seconds)	3
Dimensions in mm (L x W x H)	493 x 222 x 375
Weight in kg	11,5
Standards	EN60974-1 / IEC60974-1
